QSAN XCubeNAS XN3004R (XN3004R)

Intel® 64-bit Dual-Core, 4GB DDR3 (MAX 8GB), Support 10 GbE RJ45 or SFP+, Up to 64TB


Не нашли то, что искали?

Оставьте запрос и наши менеджеры подберут нужную модель!


ArchitectureSingle Controller
Storage OSQSM 3
CPU
ProcessorIntel®
CPU Architecture64-bit
CPU FrequencyDual-Core
Memory
Memory Module Pre-installed4GB DDR3L SO-DIMM
Total Memory Slots1
Memory Expandable up to8GB
Notes-
Storage
Drive Bays

3.5" Slot x 4

Maximum Drive Bays with Expansion Unit-
Compatible Drive Type

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

M.2 SSD

Drive Interface

SATA 6Gb/s (backward compatible with SATA 3Gb/s)

Maximum Internal Raw Capacity64TB
Maximum Raw Capacity with Expansion Units-
Hot Swappable Drive
Notes
  • For more information, please refer to compatibility matrix and hardware manual
  • Maximum internal raw capacity= 16 TB drive x 4
  • Capacity may vary by RAID types
  • M.2 SSD can be installed
External Port
USB 2.0 Port2 (Rear)
USB 3.0 Port-
HDMI Port-
OthersConsole Port x 1
Notes-
Connectivity Port
1GbE RJ45 LAN Port2 (Onboard)
10GbE RJ45 LAN Port2 (Option:RHBE10R2)
10GbE SFP+ LAN Port2 (Option:XN-E1002)
Thunderbolt 3-
16Gb SFP+ Fibre Channel-
Notes

For more information, please refer to accessory book

Please refer to the section below for expansion slot specification

Expansion Port
12Gb/s SAS Wide Port-
Notes-
PCIe Expansion
Gen3x8 Slot-
Gen3x4 Slot-
NotesGen2x8 Slot x1, For more information, please refer to hardware manual
Host Card Expansion
Gen3x8 Slot-
Gen2x4 Slot-
Notes-
Appearance
Dimension (H x W x D) (mm)44 x 438 x 370
Chassis Form Factor12″ Rackmount 1U 4 Bay
Net Weight (kg)5.97
Gross Weight (kg)9.9
Notes-
Memory Protection
Cache-to-Flash Module-
Battery Backup Module + Flash Module-
Notes-
Others
System Fan40mm x 40mm x 2 pcs
Replaceable System Fan-
Power Recovery-
Scheduled Power On/Off-
Wake on LAN/WAN-
Power Supply Unit / AdapterFLEX ATX 200W
Redundant Power Supply-
AC Input Power Voltage100V-240V
Power Frequency50-60 Hz, Single Phase
Power Consumption105 W (Access)
72 W (HDD Hibernation)
British Thermal Unit360 BTU/hr (Access)
244 BTU/hr (HDD Hibernation)
LCM Support
Notes-
Environment Temperature
Operating Temperature0 to 40°C
Storage Temperature-10 °C to 50 °C
Operating Relative Humidity20% to 80% non-condensing
Non-operating Relative Humidity10% to 90%
Notes-
Certification
Certifications

CE

FCC

BSMI

VCCI

RCM

Notes-
Warranty
Standard Warranty3 years
Notes-

Entry Level Enterprise Storage for Everyone

The XN3004R provides enterprise-class features such as unified storage systems and data compression at an affordable price. Support cloud synchronization and multi-point data backup. Double protection of software and hardware effectively prevents the risk of data theft and tampering.

  • NVR Storage Solution
    The NVR software can view, play back, manage, and store multiple network cameras simultaneously through the iSCSI connection of the XN3004R. And with online compression, optimize storage space usage, greatly improve the monitoring image retention period, and provide an affordable and reliable storage solution.
  • Light Private Cloud Storage
    QSM's built-in web-based file manager and remote backup greatly improve the efficiency of data and backup management. In addition, the XN3004R provides advanced storage technology and security solutions to enhance data security and more efficient use of storage space within a limited budget.
  • Easy Deployment, Easy to Operate
    The QSM operating system interface is simple and easy to operate, making settings such as file sharing and permissions easy. Through archival services and cloud synchronization, you can connect members of the company department to provide enterprise-level file sharing and backup at the entry price.

Enterprise Storage Technology

  • Enterprise Storage Function
    QSM provides enterprise-class storage capabilities, such as Unified Storage and Compression, enabling users to deploy elastically and increase storage space efficiency.
  • XMirror
    XMirror supports NAS multi-point backup and permission backup. It can synchronize folder or logical volume content between multiple XCubeNAS devices. When an accident occurs, it can use the backup on other devices to achieve disaster recovery, and can easily design multi-layer backup. Provide the best protection.
  • Cloud Synchronization
    Use XN3004R to perform file fast reading and writing on the local end, and transmit it to the cloud through cloud synchronization function, make full use of edge calculation, speed up data processing and transmission speed, and reduce delay to achieve maximum efficiency.
  • Software and Hardware Double Protection
    Files written under single-write multiple read (WORM) protection can only be read for a defined period of time, protecting data from ransomware attacks. And the hard disk self-encryption (SED) function, even if the disk itself is stolen, still have to use a dedicated authentication key to access, without worrying about the risk of data leakage.

Recommended Application Areas: Digital Monitoring, Data Sharing and Backup Management

  • Small Shopping Malls
  • Small and Medium-Sized Schools
  • Corporate Departments
  • Studios

Быстрый доступ к файлам

  • Web Finder
    Не требуется установки приложений, вы можете легко найти свой NAS
  • XFinder
    XFinder - утилита для поиска XCubeNAS в локальной сети
