QSAN XCubeNAS XN5004T (XN5004T)

Intel® Celeron® 2.9GHz Dual-Core Processor, 8GB DDR4 SO-DIMM (Max 32GB), инновационный дизайн слотов для накопителей N+1, 4 x 1GbE Network Interface


Не нашли то, что искали?

Оставьте запрос и наши менеджеры подберут нужную модель!


ArchitectureAll-in-one
Storage OSQSM 3
CPU
ProcessorIntel® Celeron®
CPU Architecture64-bit
CPU FrequencyDual-Core 2.9GHz
Memory
Memory Module Pre-installed8GB DDR4 SO-DIMM
Total Memory Slots2
Memory Expandable up to32 GB
Notes-
Storage
Drive Bays

3.5" Slot x 4

2.5" Slot x 1

Maximum Drive Bays with Expansion Unit-
Compatible Drive Type

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

Drive Interface

SATA 6Gb/s
(backward compatible with SATA 3Gb/s)

Maximum Internal Raw Capacity68TB
Maximum Raw Capacity with Expansion Units-
Hot Swappable Drive
Notes
  • For more information, please refer to compatibility matrix and hardware manual
  • Maximum internal raw capacity= 16 TB drive x 4 + 3.84 TB drive x 1
  • Capacity may vary by RAID types
External Port
USB 2.0 Port-
USB 3.0 Port5 (Front: 1, Rear: 4)
HDMI Port1
Others-
Notes-
Connectivity Port
1GbE RJ45 LAN Port4 (Onboard)
10GbE RJ45 LAN Port2 (Option: THBE10R2)
10GbE SFP+ LAN Port2 (Option: XN-E1002)
Thunderbolt 32 (Option: XN-TB302)
16Gb SFP+ Fibre Channel-
Notes

For more information, please refer to accessory book

Please refer to the section below for expansion slot specification

Expansion Port
12Gb/s SAS Wide Port-
Notes-
PCIe Expansion
Gen3x8 Slot1
Gen3x4 Slot-
NotesFor more information, please refer to hardware manual
Host Card Expansion
Gen3x8 Slot-
Gen2x4 Slot-
Notes-
Appearance
Dimension (H x W x D) (mm)177 x 190 x 235
Chassis Form FactorTower 4+1 Bay
Net Weight (kg)3.6
Gross Weight (kg)4
Notes-
Memory Protection
Cache-to-Flash Module-
Battery Backup Module + Flash Module-
Notes-
Others
System Fan120mm x 120mm x 1 pcs
Replaceable System Fan-
Power Recovery
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / AdapterFLEX ATX 200W
Redundant Power Supply-
AC Input Power Voltage100V-240V
Power Frequency50-60 Hz, Single Phase
Power Consumption-
British Thermal Unit-
LCM Support
Notes-
Environment Temperature
Operating Temperature0 to 40°C
Storage Temperature-10°C to 50°C
Operating Relative Humidity20% to 80% non-condensing
Non-operating Relative Humidity10% to 90%
Notes-
Certification
Certifications

CE

FCC

BSMI

VCCI

RCM

KCC

SASO

EAC

Notes-
Warranty
Standard Warranty2 years
Notes-

Быстрый доступ к файлам

  • Web Finder
    Не требуется установки приложений, вы можете легко найти свой NAS
  • XFinder
    XFinder - утилита для поиска XCubeNAS в локальной сети

Lightest SMB Multi-function Data Center

  • WORM
    WORM technology is designed to prevent intentional modification and help your data away from ransomware attacks.
  • XReplicator
    The most reliable and efficient PC backup solution on XCubeNAS.
  • XMirror
    You can regularly synchronize a volume or the contents of a folder between multiple XCubeNAS devices.
  • Rsync
    Data copies can be distributed to your trusted storage locations through real-time remote backup.
  • Snapshot Replication
    Transporting snapshots to multiple XCubeNAS to help administrators utilize the storage capacity and secure your data.
  • File Retention
    Automatically file management increases the efficiency of the storage capacity.

Идеальная архитектура

  • Увеличьте производительность, используя SSD кэширование
  • Корпус со скрытой вентиляцией
  • Управление скоростью вращения вентилятора
  • Установка без использования инструментов
  • Простой и интуитивно понятный
  • Магнитный ключ
